Future Rotor Balancing with Balanset-1A
The Balanset-1A system (hereinafter referred to as "the Device") is a portable kit designed for balancing rotors operating in their own bearings. This device allows for balancing in one or two planes, significantly increasing the service life of machines and mechanisms by reducing dynamic loads on bearing units. The kit includes two vibration sensors, a phase angle sensor, and a measuring unit.
Features and Applications
On-site balancing: The device enables the rotor to be balanced directly in its bearings, eliminating the need for special machines and mechanism disassembly. This simplifies the process and saves time.
Automated system: The entire balancing process, from measurement to the installation of corrective weights, is managed automatically. The user does not need additional skills beyond what is provided in the instructions.
Record keeping: All balancing results are saved in the Balancing Archive and can be printed as protocols if needed.
Additional capabilities: The Balanset-1A device can also function as a regular vibrometer to measure the root mean square (RMS) value of total vibration, the RMS value of the rotational component of vibration, and the rotational speed of the rotor. Additionally, it displays vibration velocity time function and spectrum graphs, which can be useful for assessing the technical condition of the balanced machine.
Package Contents and Operating Principle
The standard package includes a measuring unit, two vibration sensors, a phase angle sensor, the necessary accessories, and a flash drive with software. The device operates based on the measurement of mechanical vibrations. Vibration sensors convert the vibrations into an electrical signal, which is then processed by the measuring unit and transferred to a computer for further processing and analysis.
Balancing Recommendations. Vibrometer mode
Condition of machinery: Balancing should only be performed on mechanisms that are in good technical condition and securely mounted on their foundations. It is not recommended to balance mechanisms with worn or damaged bearings.
Rotor cleaning: Before starting work, the rotor should be cleaned of any contaminants.
Resonance: If measurement results differ significantly from run to run, this may indicate resonance. In this case, the rotational speed should be changed or the installation conditions on the foundation should be altered.
Vibrometer mode measurements: Preliminary measurements in vibrometer mode are recommended. If the total vibration value matches the rotational component, the rotor imbalance is the main contributor to vibration, and balancing can proceed.
Static imbalance check: For rotors with horizontal shafts, static imbalance can be checked manually by rotating the rotor 90 degrees. If imbalance is detected, a balancing weight should be installed.
Conclusion
Employing the Balanset-1A device ensures effective and quick rotor balancing, improving their performance and extending their service life. This is a versatile solution for those involved in the maintenance and repair of rotating mechanisms. |
|
